1．输送带通过输送带扣连接，接头处只能达到带体额定拉伸强度的70%左右，容易造成接头处的断裂；
1. The conveyor belt is connected through the conveyor belt buckle, and the joint can only reach about 70% of the rated tensile strength of the belt body, which is easy to cause fracture at the joint;
2．输送带接头直接通过输送带扣连接，输送带扣与带体垂直布置，受力更加集中，长时间在高强度拉力的工作条件下， 输送带扣与带面容易出现拔脱，造成断带；
2. The conveyor belt joint is directly connected through the conveyor belt buckle. The conveyor belt buckle is vertically arranged with the belt body, and the stress is more concentrated. Under the working conditions of high-strength tension for a long time, the conveyor belt buckle and the belt surface are easy to pull out, resulting in belt breakage;
3．输送带扣与带体垂直布置，由于输送带中间的托辊承载70%的物料重量，两侧托辊各承载15%，这样输送带扣与各个滚筒托辊直线撞击擦过，导致输送带扣中间部分磨损严重；
3. The conveyor belt buckle is arranged vertically with the belt body. Since the idler in the middle of the conveyor belt carries 70% of the material weight and the idler on both sides carries 15%, the conveyor belt buckle collides with each drum idler in a straight line, resulting in serious wear of the middle part of the conveyor belt buckle;
4．输送带主要采用的刮板式清扫器安装在卸载滚筒的下方，清扫器的刮板与输送带扣直线撞击过去，导致输送带扣和清扫器刮板磨损严重。
4. The scraper sweeper mainly used by the conveyor belt is installed below the unloading drum. The scraper of the sweeper collides with the conveyor belt buckle in a straight line, resulting in serious wear of the conveyor belt buckle and the scraper of the sweeper.
织物输送带用带扣斜式连接结构，属于织物输送带连接扣技术领域， 是一种采用倾斜结构布置，能够有效增加输送带额定拉伸强度，减少受力集中，避免断带，降低输送带扣的磨损。

The utility model relates to a belt buckle inclined connection structure for a fabric conveyor belt, which belongs to the technical field of fabric conveyor belt connection buckle. It adopts an inclined structure arrangement, which can effectively increase the rated tensile strength of the conveyor belt, reduce stress concentration, avoid belt breakage and reduce the wear of the conveyor belt buckle.
织物输送带用带扣斜式连接结构，所采用的技术方案为织物输送带通过织物输送带扣连接，织物输送带扣之间贯穿有串条， 织物输送带的接头端为斜边，斜边与织物输送带带边的夹角为45°，沿织物输送带的接头端依次钉上斜式输送带扣，本技术广泛用于织物输送带的接头连接。
The fabric conveyor belt adopts a belt buckle inclined connection structure. The adopted technical scheme is that the fabric conveyor belt is connected through the fabric conveyor belt buckle, and a string of strips are penetrated between the fabric conveyor belt buckles. The joint end of the fabric conveyor belt is an inclined edge, and the included angle between the inclined edge and the belt edge of the fabric conveyor belt is 45 °. The inclined conveyor belt buckle is nailed successively along the joint end of the fabric conveyor belt, The technology is widely used for joint connection of fabric conveyor belt.
织物输送带用带扣斜式连接结构，包括织物输送带，织物输送带通过输送带扣连接，输送带扣之间贯穿有串条，织物输送带的接头端为斜边，斜边与织物输送带带边的夹角为45°，沿织物输送带的接头端依次钉上斜式输送带扣。
The belt buckle inclined connection structure for the fabric conveyor belt includes the fabric conveyor belt. The fabric conveyor belt is connected through the conveyor belt buckle, and a string of strips are penetrated between the conveyor belt buckles. The joint end of the fabric conveyor belt is an inclined edge, and the included angle between the inclined edge and the belt edge of the fabric conveyor belt is 45 °. The inclined conveyor belt buckle is nailed successively along the joint end of the fabric conveyor belt.
