输送带接口方式有哪些规范特点?

来源:http://www.huafengxiangsu.com 时间:2020-10-13 14:47:59 浏览次数:0
1、冷粘接头。即采用冷粘粘合剂来进行接头。
1. Cold bonded joints. That is, cold adhesive is used for joint.
优点:这种接头办法比机械接头的效率高,也比较经济,应该可以有比较好的接头效果,但是从实践来看
Advantages: this joint method is more efficient and economical than mechanical joint. It should have better joint effect, but from the perspective of practice
缺点:由于工艺条件比较难掌握(熟知并能运用) ,另外粘合剂的质量对接头的影响非常大,所以不是很稳定(解释:稳固安定;没有变动)。用冷粘胶粘接相当于输送带自身强度的40%-55%。
Disadvantages: because the process conditions are difficult to master (familiar and able to use), in addition, the quality of the adhesive has a great impact on the joint, so it is not very stable (explanation: stable and stable; no change). With cold adhesive bonding equivalent to 40% - 55% of the strength of the conveyor belt itself.
2、机械接头。橡胶输送带有耐热带、耐磨带、耐灼烧带、耐油带、耐碱带、耐碱带、耐热带、耐寒带等特性。 主要用于各矿山、冶金、钢铁、煤炭、水电、建材、化工、粮食等企业的固体物料输送。
2. Mechanical joint. Rubber conveyor belt has the characteristics of heat resistance, wear resistance, burning resistance, oil resistance, alkali resistance, alkali resistance, tropical resistance and cold resistance. It is mainly used for conveying solid materials in mines, metallurgy, steel, coal, hydropower, building materials, chemical industry, grain and other enterprises.
优点:一般是指使用皮带扣接头,这种接头方法方便便捷,也比较经济,聚氯乙烯和PVG整芯阻燃抗静电(是一种处于静止状态的电荷)输送带接头中,一般8级带以下的产品都采用这种接头方法。
Advantages: it generally refers to the use of belt buckle joint, which is convenient, convenient and economical. In PVC and PVG whole core flame retardant and antistatic (it is a kind of static charge) conveyor belt joint, it is generally used for products below grade 8 belt.
大倾角输送带
不好的地方:但是接头的效率低,容易损坏,对输送带产品的使用寿命有一定影响。用卡扣连接相当于输送带自身强度的28%-45%。
Bad place: but the efficiency of the joint is low, easy to damage, has a certain impact on the service life of the conveyor belt products. It is equivalent to 28% - 45% of the strength of the conveyor belt itself.
3、热硫化接头。
3. Hot vulcanized joint.
优点:实践证明是更理想的一种接头方法,可以保证高的接头效率,同时也非常稳定(解释:稳固安定;没有变动),接头寿命也很长,容易掌握(熟知并能运用) 。输送带厂家是带式输送机的主要部件,主要用于煤炭、矿山、冶金、化工、建筑和交通等部门的大规模连续化运输,运输的物料分为块状、粉状、糊状和成件物品等。从微观构成来看,输送带主要由骨架材料、覆盖层及打底材料三大部分组成,其中覆盖层为决定其性能及用途的关键部分。
Advantages: it has been proved to be the most ideal joint method, which can ensure high joint efficiency and is very stable at the same time (explanation: stable and stable; no change), long joint life, easy to master (familiar and able to use). Conveyor belt manufacturer is the main component of belt conveyor, which is mainly used for large-scale continuous transportation of coal, mining, metallurgy, chemical industry, construction and transportation departments. The materials transported are divided into block, powder, paste and finished products. From the microcosmic point of view, the conveyor belt is mainly composed of skeleton material, covering layer and backing material, and the covering layer is the key part to determine its performance and application.
不好的地方:但是存在工艺麻烦、费用高、接头时间长等缺点。用机械热硫化粘结相当于输送带自身强度的60%-80%。
Disadvantages: however, there are some disadvantages such as troublesome process, high cost and long joint time. Mechanical hot vulcanization bonding is equivalent to 60% - 80% of the strength of the conveyor belt itself.
