1. Put a flexible shaft on the coiling core of the conveyor belt, and make the belt roll well. Pay attention to the direction of the upper and lower cover glue before putting it on the frame. The conveyor belt is divided into ordinary conveyor belt and strong conveyor belt according to the tensile strength of belt cloth layer. Strong canvas conveyor belt is divided into nylon conveyor belt (NN conveyor belt) and polyester conveyor belt (EP conveyor belt). The heat-resistant conveyor belt is made of multi-layer rubber cotton canvas (polyester cotton cloth) or polyester canvas covered with high-temperature or heat-resistant rubber. It is suitable for conveying hot coke, cement, slag and hot casting below 175 ℃.

2、在不宜上架的工作场所可以把输送带卷导开，并使折叠（含义:把物体的一部分折过)处输送带具有足够大曲率半径，防止损伤输送带，折叠（含义:把物体的一部分折过)处禁止在输送带上放置重物。

2. In the workplace that is not suitable to be put on the shelf, the conveyor belt can be rolled away, and the folding (meaning: folding a part of the object) of the conveyor belt has enough curvature radius to prevent damage to the conveyor belt. It is forbidden to place heavy objects on the conveyor belt at the folding (meaning: folding part of the object).

3、如果是更换输送带，可将新带与旧带连在共同，卸带与安装新输送带同时进行。

3. If the conveyor belt is replaced, the new belt can be connected with the old belt, and the unloading and installation of the new belt can be carried out at the same time.

4、对于水平运转的输送机，可在任何一点切断（割开；截断)旧输送机，倾斜方向运转的输送机，则需选好切断点，防止因自重引起下滑而失控。

4. For the horizontal running conveyor, the old conveyor can be cut off at any point; for the conveyor running in the inclined direction, the cut-off point should be selected to prevent the slide caused by the self weight and out of control.

5、在输送机上将新带的位置（position )放正后，用夹具将胶带的一端固定(fixed)好，然后与绕过辊（gǔn)与带轮的绳索相连，通过(tōng guò)牵引装置将输送带平衡地架到输送机上，牵引时，要防止输送带与机架相互挤压。

5. After the position of the new belt is put in the right position on the conveyor, one end of the belt is fixed with a clamp, and then it is connected with the rope that bypasses the roller (g ǔ n) and the belt pulley. The conveyor belt is balanced on the conveyor through the (t ō ng gu) traction device. During traction, it is necessary to prevent the conveyor belt and the frame from squeezing each other.

6、用夹具将输送带的一端固定(fixed)在输送机架上，另一端通过(tōng guò)滑轮(pulley)将另一端拉紧，直到输送带在返回托辊(支撑输送带和物料重量)（gǔn)上无明显下垂。

6. One end of the conveyor belt is fixed on the conveyor frame with a clamp, and the other end is tightened by a pulley (t ഊ ng Gu ò) until there is no obvious sag of the conveyor belt on the return idler (supporting the belt and material weight) (g ǔ n).

7、将张紧装置固定(fixed)离起点100~150mm。

7. Fix the tensioning device 100 ~ 150 mm from the starting point.

如果您想了解(Find out)更多的关于输送带方面的技术问题(Emerson)或疑惑，请致公司(Company)，我们随时恭候您的来电。耐热输送带主要用于冶金、建筑等行业，输送烧结矿、焦炭、水泥熟料等高温物料，物料温度不超过800℃，带面温度不超过220℃的条件下使用。 特性：采用三元乙丙橡胶为覆盖层，主要是根据耐热带破损以丧失输送能力的主要表现和不同的耐热级别。

If you want to know more about Emerson or doubt about conveyor belt, please call company, we are always waiting for your call. Heat resistant conveyor belt is mainly used in metallurgy, construction and other industries to transport sinter, coke, cement clinker and other high-temperature materials. The material temperature is not more than 800 ℃ and the belt surface temperature is not more than 220 ℃. Characteristics: EPDM is used as the covering layer, mainly according to the main performance of resistance to tropical damage and loss of transport capacity and different heat resistance grades.
