带式输送机的跑偏有什么规律?

来源:http://www.huafengxiangsu.com 时间:2019-09-20 15:13:13 浏览次数:
  带式输送机在运行过程中,输送带中心线与输送带中心线向一侧偏离。偏置是带式输送机的常见故障之一。长时间的偏差不仅会造成皮带边缘的严重磨损,还会引起皮带撕裂、刮擦等突发事故。下面,输送带厂家分享输送带偏差规律。
  During the operation of belt conveyor, the center line of conveyor belt deviates from the center line of conveyor belt to one side. Offset is one of the common faults of belt conveyor. Long time deviation will not only cause serious wear of belt edge, but also cause belt tear, scratch and other sudden accidents. Below, conveyor belt manufacturers share conveyor belt deviation rules.
  1. 运行松动,不紧:运行时前后滚轮中心线不平行于带式输送机,导致输送带两侧密封性不同,输送带会向松动一侧移动。
  1. Loose and loose operation: the center line of the front and rear rollers is not parallel to the belt conveyor during operation, which results in different sealability on both sides of the conveyor belt, and the conveyor belt will move to the loose side.
  2. 跑高不跑低:托辊与胶带跑向平行的水平位置不相同,但一端高,一端低,胶带就会跑向胶带高的一侧。
  2. Running high, not running low: the roller and tape run parallel to the horizontal position is different, but one end is high, one end is low, the tape will run to the high side of the tape.
  3.运行后不运行前:托辊不在垂直于皮带运行方向的横截面上,而是一端在前,一端在后(参照皮带运行方向),则皮带后端会移动。
切菜机输送带
  3. Before running: the idler is not on the cross section perpendicular to the running direction of the belt, but on the front end and on the back end (referring to the running direction of the belt), the back end of the belt will move.
  4. 大跑,不小跑:滚筒外表面增加t误差,煤卡或磨损不均匀造成直径不一致,胶带跑到直径较大的一侧。
  4. Run big, run small: the outer surface of the drum increases T error, coal cards or uneven wear cause diameter inconsistency, tape runs to the larger side of the diameter.
  现在输送带的使用越来越普遍,很多企业都需要输送带来满足项目流程。而输送带的使用也有很多注意的地方,以上输送带厂家为您总结了输送带偏离规律的知识,希望对广大用户有所帮助。
  Now the use of conveyor belts is becoming more and more common, many enterprises need conveyor belts to meet the project process. And the use of conveyor belts also has a lot of attention, the above conveyor belt manufacturers summarized the knowledge of conveyor belt deviation rules for you, hoping to help the majority of users.
