大倾角输送带的硫化加工设备主要有哪些分类?

来源:http://www.huafengxiangsu.com 时间:2019-02-25 14:07:14 浏览次数:
(1) 大平板硫化机:大平板硫化机为长方形框架结构,宽度多为1.4-2.2m,长度8-10m。世界上大的平板为宽度3.8m,长度15.6m。大平板硫化机基本上是液压驱动, 热源有蒸汽和热油,平板压力由油压系统提供。
(1) Large plate vulcanizer: The large plate vulcanizer is rectangular frame structure with a width of 1.4-2.2m and a length of 8-10m. The largest flat plate in the world is 3.8m in width and 15.6m in length. The large plate vulcanizer is basically driven by hydraulic pressure. The heat source is steam and hot oil. The plate pressure is provided by the hydraulic system.
(2) 鼓式硫化机:鼓式硫化机可进行大倾角输送带的接连硫化,规范φ700Χ1500mm到φ1500Χ2600mm,世界上大的鼓式硫化机为φ2000Χ3200mm。鼓式硫化机经过 转鼓对大倾角输送带进行加热,以胶带或钢带进行加压,硫化压力小于大平板硫化机。鼓式硫化机价格高,出产功率低,目前多限硫化薄层大倾角输送带。
大倾角输送带
(2) Drum vulcanizing machine: Drum vulcanizing machine can carry out continuous vulcanization of conveyor belt with large inclination angle. Specification_700_1500 mm to_1500_2600 mm. The largest drum vulcanizing machine in the world is_2000_3200 mm. The drum vulcanizer heates the conveyor belt with large inclination angle through the drum, and pressurizes it with the belt or steel belt. The vulcanization pressure is less than that of the large plate vulcanizer. Drum vulcanizing machine has high price and low output power. At present, Multi-Limit vulcanizing thin layer conveyor belt with large inclination is used.
(3) 接连式平板硫化机:接连式平板硫化机有兼平板硫化机和鼓式硫化机的特点,可接连硫化各种高强度、大厚度大倾角输送带,特别适合于硫化和塑化需冷却出锅 的整芯大倾角输送带。 接连式平板硫化机有上下各二块热板,热板与带坯之间各加有一条环形滚子链和环形钢带,滚子链和钢带各有一套独立的翻滚设备。硫化时带坯被夹在两条钢带之间由 热板经过热转导加热而硫化,并经过热板、滚子链和钢带对硫化带坯加压,硫化时上下两环形钢带与带坯一同接连工作完成带坯的接连硫化。
(3) Continuous plate vulcanizing machine: Continuous plate vulcanizing machine has the characteristics of both plate vulcanizing machine and drum vulcanizing machine. It can be used to vulcanize various high strength, large thickness and large inclination conveyor belts, especially for whole core conveyor belts with large inclination which need to be cooled out of the pot during vulcanization and plasticization. There are two hot plates in the continuous plate vulcanizer, one ring roller chain and one ring steel belt between the hot plate and the strip. Each roller chain and the strip has a set of independent rolling equipment. During vulcanization, the strip is clamped between two strips and vulcanized by heat transfer heating of the hot plate. The strip is pressurized by hot plate, roller chain and strip. During vulcanization, the upper and lower ring strips work together with the strip to complete the continuous vulcanization of the strip.
