Conveyor belt is an important part of the conveyor, which accounts for more than half of the total cost of the conveyor, so it is particularly important for the conveyor belt of the assembly line how to maintain in the daily operation. Today our technician will give you an analysis of a very common conveyor belt maintenance, it is nylon conveyor belt.

尼龙输送带的保养和维护主要是以下几点：

The maintenance of nylon conveyor belt mainly includes the following points:

1、给料方向应顺胶带的运行方向，为减小物料下落时对胶带的冲击应采溜槽，减小物料下落距离;胶带受料段应缩短托辊间距和采用缓冲托辊为漏料，带顺应采用柔软适度的挡料板，以免档料板过硬，刮破输送带的带面。

1. The feeding direction should be along the running direction of the belt. In order to reduce the impact of the material falling on the belt, the chute should be adopted to reduce the falling distance of the material; the distance between the rollers should be shortened in the receiving section of the belt, and the buffer roller should be used as the leakage material, and the soft and moderate baffle should be used to avoid the material baffle being too hard and scraping the belt surface of the conveyor belt.

2、不同类型、规格层数的输送带不宜接在一起使用，其接头**采用胶接法。

2. The conveyor belts of different types and specifications should not be connected together, and their joints * * should be glued.

3、输送胶带运行速度一般不宜大于2.5米/秒，块度大，磨损性大的物料和使用固定梨的卸料装置应尽量采用低速。

3. In general, the running speed of conveyor belt should not be greater than 2.5 m / s. low speed should be used as far as possible for materials with large block size and wear and unloading device using fixed pear.

4、输送带在使用中应注意以下事项：①避免托辊被物料覆盖，造成回转不灵，防止漏料卡于滚筒与胶带之间，注意活动部分的润滑，但不得油污输送胶带;②避免带负荷启动;③胶带发生跑偏，应用时采取措施纠正;④发现胶带局部损人造棉应用时修补，以免扩大;

4. The following points should be paid attention to in the use of the conveyor belt: ① avoid the idler being covered by materials, resulting in ineffective rotation, prevent leakage from being stuck between the drum and the belt, pay attention to the lubrication of the moving part, but do not grease the conveyor belt; ② avoid starting with load; ③ take measures to correct the deviation of the belt; ④ repair the belt when it is found that it is damaged by human and cotton making, so as to avoid expansion;

5、输送机的传动滚筒直径与输送带布层的关系、传动滚筒、改向滚筒的配套以及对托辊槽角的要求应根据运输机的设计规定，合理选取。

5. The relationship between the diameter of driving drum and the distribution of conveyor belt, the matching of driving drum and turning drum, and the requirements for groove angle of idler should be reasonably selected according to the design regulations of conveyor.

6、输送胶带的类型、结构、规格、层数应根据使用条件合理选用。

6. The type, structure, specification and number of layers of conveyor belt should be selected reasonably according to the use conditions.

关于食品级输送带https://www.huafengxiangsu.com  就先介绍到这里了，相信大家在实际的工作中会用到相关知识，如果您有这方面的需要，欢迎前来选购。

About food grade conveyor belt https://www.huafengxiangsu.com  First of all, I believe that you will use the relevant knowledge in the actual work, if you have the need in this respect, welcome to buy.
