The high angle wavy sideband is composed of base band, sideband and diaphragm. The edge guard is used to prevent the material from sliding and scattering. In order to bypass the drum, the baffle edge is designed to be corrugated; the diaphragm plate is used to support materials, in order to achieve high angle transportation, T-type TC type is used. The baffle and diaphragm are connected with the baseband by the method of secondary vulcanization, with high connection strength

产品特点(普通型大倾角波状挡边输送带)：

Product features (ordinary large angle corrugated edge retaining conveyor belt):

1、增大了输送角度(30~90度)；

1. Increase the conveying angle (30-90 degrees);

2、占地面积小，投资少；

2. Small area and less investment;

3、输送量大、提升高度更高；

3. Large conveying capacity and higher lifting height;

4、从水平到倾斜(或垂直)能平稳过渡；

4. Smooth transition from horizontal to inclined (or vertical);

5、适宜输送易撒落的粉状、粒状、小块状、糊状及液态状物料；

5. Suitable for conveying powder, granular, small, paste and liquid materials which are easy to be scattered;

6、能耗低、结构简单、胶带强度高、使用寿命长。

6. Low energy consumption, simple structure, high belt strength and long service life.

3、品种

3. Variety

称裙边隔板带输送带

Scale skirt partition belt conveyor belt

简介：1、产品介绍（普通型大倾角波状挡边输送带）

Introduction: 1. Product introduction (ordinary large angle corrugated edge conveyor belt)

大倾角波状挡边带由基带、挡边、横隔板3部分组成。挡边起防止物料测滑撒落的作用。为便于绕过滚筒，档边设计成波纹状；横隔板的作用是承托物料，为了实现大倾角输送，采用T型TC型。档边和横隔板是用二次硫化的方法与基带连接的，具有很高的连接强度

The high angle wavy sideband is composed of base band, sideband and diaphragm. The edge guard is used to prevent the material from sliding and scattering. In order to bypass the drum, the baffle edge is designed to be corrugated; the diaphragm plate is used to support materials, in order to achieve high angle transportation, T-type TC type is used. The baffle and diaphragm are connected with the baseband by the method of secondary vulcanization, with high connection strength

产品特点（普通型大倾角波状挡边输送带）：

Product features (ordinary large angle corrugated edge retaining conveyor belt):

1、增大了输送角度(30~90度)；

1. Increase the conveying angle (30-90 degrees);

2、占地面积小，投资少；

2. Small area and less investment;

3、输送量大、提升高度更高；

3. Large conveying capacity and higher lifting height;

4、从水平到倾斜（或垂直）能平稳过渡；

4. Smooth transition from horizontal to inclined (or vertical);

5、适宜输送易撒落的粉状、粒状、小块状、糊状及液态状物料；

5. Suitable for conveying powder, granular, small, paste and liquid materials which are easy to be scattered;

根据覆盖胶性能不同分为普通型、耐热型、难燃型、耐寒型、耐酸碱型、耐油型等。

According to the different properties of covering rubber, it can be divided into common type, heat-resistant type, flame-retardant type, cold resistant type, acid and alkali resistant type, oil resistant type, etc.
